| General | |
|---|---|
| Interface, Front | RJ45 |
| Interface, Rear | IDC Insulation Displacement Contact |
| Cable Type | Unshielded/Shielded Cable |
| Panel Cutout | 14.38X16.02 mm |
| Termination Tool | Toolless, Not required Termination tool |
| Color | Shielded – Metallic, Unshielded – Back, White, Blue, Yellow, Red, Other by request. |
| Support Application | IEEE 802.11x | IEEE 802.3 |10/100Base-TX | 1000 BASE T (Gigabit Ethernet) | 1000 BASE TX (Gigabit Ethernet) | EEE 802.3an 10G BASE-T | 10G BASE-T (TSB-155) | 4/16 Token Ring | ATM 155/622Mbps | ATM 1.2Gbps | ISDN ANSI-EIA / TIA-854 | ANSI-EIA / TIA-862 | Broadcast Analog and Digital Video | PoE IEEE 802.3af & IEEE802.3at | PoE IEEE 802.3bt type 3 & type 4 | Building Automation Systems |
| Standard Compliant | TIA/EIA 568-C.2 | TIA/EIA 568.2-D | CATEGORY 6 | TIA 942B ISO/IEC 11801: 2017 CLASS E | EN50173-1 RoHS Compliant | REACH Compliant | Lead-Free IEC 60603-7 | IEC 60512 | FCC Part 68 SUBPART F |
| Material Properties | |
| Modular Jack Housing | Shielded, Zinc Alloy Electroplating 360° Shielded. Unshielded, Fire Proof Polycarbon |
| Housing Flame Rating | UL 94 V-0 |
| Termination Blocks | Fire Proof Polycarbonate, UL 94 V-0 |
| Pin Contact | Phosphor Bronze, 50µ Inch Gold Plating |
| PCB | Fire Proof Polycarbonate, UL 94 V-0 |
| IDC Terminal Contact | Phosphor Bronze Tinned Plating |
| Smart Clip Lock | Fire Proof Polycarbonate, UL 94 V-0 |
| Dimension (WXDXH) | 14.38X29.91X19.31 mm |
| Conductor Type | Solid | Stranded |
| Conductor Gauge | Solid 22–24 AWG |
| Conductor Gauge | Stranded 22-26 AWG |
| IDC Termination | 110 Insulation Displacement Contact (IDC), KRONE |
| IDC Durability | 250 times re-termination |
| Plug Insertion Life | 750 Mating Cycle |
| Plug Retention Force | 79 N |
| Wiring | T568A | T568B |
| Cable OD | 5.0 – 8.5mm |
| Smart Clip Lock | Integrated Smart Clip Lock, Re-Usable, Adjustable Cable Diameter |
